Here are the dimensions of the jibs to help with your show planning to show the length, height, and footprint of each size of jib. Arm lengths are measured from the pivot point. If you plan to place the jib on a platform, double the tail length and add about 4 feet to give the operator room for full 360 degree movement.
Name/Length Height Tail Length Weight Limit
Standard 13ft 3ft 50 lbs.
6ft
Standard Plus 16ft 3ft 50 lbs.
9ft
Giant 19ft 3ft 50 lbs.
12ft
Giant Plus 23ft 6ft 50 lbs.
15ft
Super 25ft 6ft 50 lbs.
18ft
Super Plus 30ft 6ft 50 lbs.
24ft
Extreme 33ft 9ft 50 lbs.
30ft
12 Meter 38ft 9ft 25 lbs.
40ft
